Rated output ........................200W + 200W (20Hz - 20kHz, 0.005% and 6 Ω)
170W + 170W (20Hz - 20kHz, 0.005% and 8 Ω)
240W + 240W (20Hz - 20kHz, 0.005% and 4 Ω)

Frequency characteristic ..............................20Hz - 20kHz (+0dB and -0.1dB)
0.8Hz - 150kHz (+0dB and -3dB)

Signal-noise ratio......................................... 93dB (EIAJ) 120dB (IHF ' 66)

           Input sensitivity/input impedance

Normal/DC:................................................. 1.2V/47k Ω
Balance:......................................................1.2V/600 Ω

Meter indicating range................................... 0.0001W - 300W (8 Ω)

Electric power consumption ...........................420W

Power source AC...........................................100V and 50/60Hz

External size .................................................Width 480× height 208× depth 476mm

Weight...........................................................38kg
